Fernco

Fernco 3001 Proflex Shielded Coupling – Cast Iron to Copper

In stock

SKU: 3001-150

(0)

Ships Same Day

$15.09

Express Checkout

✔ In Stock — Ships Same Day or Next Business Day
✔ Trusted by contractors and industrial buyers
✔ Bulk pricing available — Request a Quote

Buying in bulk?
Contact us for contractor pricing or large quantity discounts →

✓ Full stainless steel shield — rigid joint that resists shear, shifting & vibration
✓ Transitions cast iron, plastic or steel to copper
✓ Neoprene gasket seals tight — no primers, glue or solvent odors
✓ Conforms to ASTM C1460, ASTM C564 & CSA B602 — passes inspection

High Demand Item – Frequently Reordered by Contractors

Fernco Proflex is the all-stainless shielded transition coupling for dependable above-ground pipe connections. A flexible neoprene sleeve seals the joint while a full .012″ type 301 stainless steel shield and clamp bands lock it rigid — so the connection resists shear forces, vibration, and shifting that would loosen an unshielded coupling.

From 1-1/2″ to 2″, the 3001 series transitions cast iron, plastic or steel to copper above ground, with the same all-stainless shield and neoprene gasket as the rest of the Proflex line.

Applications

Above-ground transitions from cast iron, plastic or steel to copper
Copper DWV tie-ins on a rigid, shielded joint
Remodels and repairs joining copper to existing pipe
Commercial and residential plumbing needing a shielded copper transition

Key Features

Neoprene (synthetic rubber) gasket, marked with part number and application
.012″ type 301 stainless steel shield, 2.125″ wide
301 stainless clamp band and housing; 305 stainless 5/16″ hex screw
Rigid, shear-resistant joint for above-ground transitions
Installs with a standard nut driver or torque wrench — no primers or glue
Made in the USA — AIS and BABA compliant

Specifications

Gasket Material	Neoprene (synthetic rubber), conforms to ASTM C564
Shield	.012″ × 2.125″ type 301 stainless steel
Clamp Band & Housing	301 stainless steel
Clamp Screw	305 stainless steel, 5/16″ hex
Standards	ASTM C1460, ASTM C564, CSA B602
Installation Torque	60 in-lbs
Max Test Pressure	4.3 PSI (29.6 kPa)
Max Operating Temp	180°F
Origin	Made in USA, AIS & BABA compliant

Sizes & Connections

Part No.	Side A	Side B	Length	Mission® Eq.	Price
3001-150	1-1/2" CI, Plastic or Steel	1-1/2" Copper or 1-1/4" Plastic	2.13"	CK-115	$15.09
3001-215	2" CI, Plastic or Steel	1-1/2" Copper or 1-1/4" Plastic	2.13"	CK-215	$15.09
3001-22	2" CI, Plastic or Steel	2" Copper	2.13"	CK-22	$19.83

Mission® equivalents are listed per Fernco’s published cross-reference for sizing convenience. Mission is a trademark of its respective owner; this listing is not affiliated with or endorsed by that company.

Best Used For

Above-ground DWV, sewer, waste and vent transitions
Connecting dissimilar pipe materials on a rigid, shear-resistant joint
Repairs and remodels where a banded coupling needs the strength of a shield
Commercial and residential plumbing where code calls for a shielded coupling

FAQ

What does the 3001 series connect?

Cast iron, plastic or steel on one side to copper (or smaller plastic) on the other — a clean above-ground transition to copper DWV.

Above ground or buried?

Proflex is for above-ground transitions. For buried, load-bearing joints use a Strong Back RC coupling.

How are sizes listed?

As the CI/plastic/steel size by the copper size — for example, 2″ × 1-1/2″ Copper connects 2″ cast iron, plastic or steel to 1-1/2″ copper.

Why Contractors Choose This

Full stainless shield holds the joint rigid where rubber-only couplings flex
One coupling makes a clean material transition above ground
No primers, glue or cure time
Code-listed: ASTM C1460, ASTM C564, CSA B602
Made in the USA, AIS & BABA compliant

✓ .012″ type 301 stainless steel shield assembly
✓ 301 stainless clamp band & housing, 305 stainless screw
✓ Conforms to ASTM C1460, ASTM C564 & CSA B602
✓ Made in the USA — AIS and BABA compliant
