Suspend horizontal copper tube — hinged for fast installation. The hinge split ring swings open on a hinge to wrap around copper tube and bolts closed on the opposite side, then hangs from a threaded rod. Copper-plated (Copper Gard) finish prevents galvanic corrosion at the tube contact point.
- Hinged ring swings open, wraps the tube, and bolts closed
- Hangs from threaded hanger rod (3/8" typical)
- Hinge speeds installation vs. a standard split ring
- Copper-plated — galvanic protection for copper tube
- Manufactured to MSS SP-58 pipe support standards
✔ Used by contractors and professionals
✔ Designed for reliable jobsite performance
Overview
The hinge split ring is a fast-install variant of the classic split ring hanger. The ring is hinged on one side — it swings open, wraps around the tube, and bolts closed on the other side, then hangs from a threaded rod. The copper-plated (Copper Gard) finish matches copper tube to prevent galvanic corrosion.
Common Uses
- Suspending horizontal copper tube from decks and structural steel
- Domestic water and hydronic copper piping
- Commercial plumbing and HVAC copper runs
- Fast-paced installs where hinged hangers save labor
Key Features
- Hinged split ring — swings open for installation
- Copper-plated — galvanic-safe for copper tube
- Threaded rod connection (3/8" typical)
- CTS sizing — matches copper tube size
- Manufactured to MSS SP-58 pipe support standards
Specifications
| Type | Hinge Split Ring Hanger (Empire Fig. 41H) |
| Finish | Copper-Plated (Copper Gard) |
| Rod Connection | Threaded Rod (3/8" typ.) |
| Pipe Sizing | CTS |
| Standard | MSS SP-58 / SP-69 Type 12 |
Load Ratings by Pipe Size
Maximum recommended load by tube size, per Empire Fig. 41H engineering data. Match to your tube's nominal size and apply your project's factor of safety.
| Tube Size | Max. Rec. Load (lb) |
| 3/8–2" | 180 |
| 2-1/2–4" | 300 |
Listings & Standards
- MSS SP-58 / SP-69 Type 12
- Not UL/FM listed (MSS-compliant split ring hanger)
Competitor Cross-Reference
| PVF Pro (Empire Fig. 41H) | Cooper B-Line |
| Hinge Split Ring Hanger | B3198H |
Cross-reference is for identification only. Cooper B-Line® is a trademark of its owner, which is not affiliated with or endorsing Empire Industries or PVF Pro. Always confirm fit and load rating for your application.
Frequently Asked Questions
What is a hinge split ring?
It is a split ring with a hinged side that swings open, so you can wrap it around the tube and bolt it closed quickly — saving labor over a standard two-bolt split ring.
Why copper-plated?
Bare steel against copper tube causes galvanic corrosion. A copper-plated hanger matches the tube and eliminates that contact reaction.
