Em-Lok Adjustable Swivel Ring Hanger (3/8" Rod) Plastic Coated IPS
- ✔ In Stock — Ships Same Day or Next Business Day
- ✔ Trusted by contractors and industrial buyers
- ✔ Bulk pricing available — Request a Quote
Contact us for contractor pricing or large quantity discounts →
Couldn't load pickup availability
Adjustable swivel-ring hanger — with pipe isolation. The EM-LOK swivel ring bolts around the pipe and threads onto a hanger rod through a swivel nut; the plastic coating isolates the pipe and resists corrosion. Sized for 3/8" rod, IPS.
- Ring bolts around the pipe
- Swivel nut threads onto the hanger rod and aligns to the run
- Plastic coating isolates pipe and resists corrosion
- Sized for 3/8" threaded rod
- Manufactured to MSS SP-58 pipe support standards
✔ Used by contractors and professionals
✔ Designed for reliable jobsite performance
Overview
The swivel-ring hanger is one of the most widely used hangers for horizontal pipe. EM-LOK is Empire's adjustable swivel-ring design, with a swivel nut that threads onto the hanger rod and lets the ring align to the run. The plastic coating isolates the pipe from bare steel and adds corrosion resistance.
Common Uses
- Suspending coated or finished horizontal pipe
- Applications needing pipe-to-hanger isolation
- Damp or mildly corrosive environments
- Commercial and institutional mechanical systems
Key Features
- Adjustable swivel-ring design
- Protective plastic coating
- Sized for 3/8" threaded rod
- MSS SP-58 / SP-69 Type 10
Specifications
| Type | Adjustable Swivel Ring Hanger (Empire Fig. 310) |
| Finish | Plastic Coated |
| Rod | 3/8" |
| Pipe Sizing | IPS |
| Standard | MSS SP-58 / SP-69 Type 10 |
Load Ratings by Pipe Size
Maximum recommended load by pipe size, per Empire Fig. 310 engineering data. Match to your pipe's nominal size and apply your project's factor of safety.
| Pipe Size | Max. Rec. Load (lb) |
| 1/2–3/4" | 400 |
| 1–3-1/2" | 600 |
| 4–5" | 1,000 |
| 6–8" | 1,250 |
Listings & Standards
- MSS SP-58 / SP-69 Type 10
- UL & FM listings apply to the galvanized variants of this hanger
Competitor Cross-Reference
| PVF Pro (Empire Fig. 310) | Anvil | Cooper B-Line |
| Adjustable Swivel Ring Hanger | 69 | B3170 |
Cross-reference is for identification only. Anvil® and Cooper B-Line® are trademarks of their respective owners, which are not affiliated with or endorsing Empire Industries or PVF Pro. Always confirm fit and load rating for your application.
Frequently Asked Questions
Why a plastic-coated swivel ring?
The coating isolates the pipe from bare steel and resists corrosion — useful for finished pipe or damp environments.
What rod does it use?
This hanger is sized for 3/8" threaded rod.
