The most common way to hang horizontal pipe. The adjustable clevis hanger cradles the pipe in a two-piece clevis that bolts closed and hangs from a threaded rod — the standard choice for supporting horizontal pipe runs from the structure above. Type-316 stainless steel for maximum corrosion resistance.
- Two-piece clevis cradles the pipe and bolts closed
- Hangs from threaded hanger rod (3/8" typical)
- Vertical adjustment at the rod for precise alignment
- Type-316 stainless steel for chloride, marine, and chemical environments
- Manufactured to MSS SP-58 pipe support standards
✔ Used by contractors and professionals
✔ Designed for reliable jobsite performance
Overview
The adjustable clevis hanger is the workhorse of horizontal pipe support. The pipe sits in the lower strap, the upper clevis bolts over it, and the assembly hangs from a threaded rod anchored to the structure above. The cross bolt allows vertical adjustment after installation. Type-316 stainless steel adds molybdenum for superior resistance to chlorides and aggressive chemicals.
Common Uses
- Suspending horizontal pipe in coastal, marine, and chloride environments
- Chemical process and wastewater facility piping
- Wet and washdown areas
- Institutional and industrial building systems
Key Features
- Two-piece adjustable clevis design
- Threaded rod connection (3/8" typical)
- Vertical adjustment after installation
- Type-316 stainless steel — maximum corrosion resistance
- Manufactured to MSS SP-58 pipe support standards
Specifications
| Type | Adjustable Clevis Hanger (Empire Fig. 11) |
| Material | T-316 Stainless Steel |
| Rod Connection | Threaded Rod (3/8" typ.) |
| Pipe Sizing | IPS |
| Standard | MSS SP-58 / SP-69 Type 1 |
Load Ratings by Pipe Size
Maximum recommended load by pipe size, per Empire Fig. 11 engineering data. Match to your pipe's nominal size and apply your project's factor of safety.
| Pipe Size | Max. Rec. Load (lb) |
| 1/2–2" | 730 |
| 2-1/2–3" | 1,130 |
| 3-1/2" | 1,350 |
| 4–5" | 1,430 |
| 6" | 1,940 |
| 7–8" | 2,000 |
| 10" | 3,600 |
| 12" | 3,800 |
| 14–30" | 4,200–6,000 |
Listings & Standards
- MSS SP-58 / SP-69 Type 1
- Stainless steel is MSS-compliant; UL & ULC / FM listings apply to the carbon-steel and galvanized finishes
Competitor Cross-Reference
| PVF Pro (Empire Fig. 11) | Anvil | Cooper B-Line | nVent CADDY |
| Adjustable Clevis Hanger | 260 | B3100 | 401 |
Cross-reference is for identification only. Anvil®, Cooper B-Line®, and CADDY® are trademarks of their respective owners, which are not affiliated with or endorsing Empire Industries or PVF Pro. Always confirm fit and load rating for your application.
Frequently Asked Questions
316 vs 304 — which do I need?
Type-316 adds molybdenum for better resistance to chlorides and harsh chemicals — preferred in coastal, marine, and aggressive process environments.
What rod size does it use?
Most sizes use 3/8" threaded rod; larger pipe may require 1/2" or larger. Confirm against your support spacing and pipe weight.
